    • Cutters with bore

    Rebating cutterhead

    As low as £284.63 Regular Price £50,000.00
    To Purchase Selection
    main product photo
    Tungsten carbide
    Tungsten carbide
    Rebating
    Rebating
    Manual feed
    Manual feed
    Light alloy body<br />
    Light alloy body
    Mechanical knife clamping, reversible
    Mechanical knife clamping, reversible

    Information

    Information
    Application: For jointing, rebating and grooving.
    Machine:

    Spindle moulders (running against feed), double-end tenoners, edgebanding machines etc. (running with feed or against feed e.g. jump cutting). Stationary routers with/without CNC control.
    Workpiece material:

    Softwood and hardwood, glulam, plastics etc.
    Technical information: Cutterhead with alternate shear angle and triangular spurs.
    Tool Selection
    i
    Id D
    mm     		SB
    mm     		BO
    mm     		BOmax
    mm     		Z
    		 V
    		 nmax
    min-1
    24723 Turnblade rebating cutterhead
    MC:125x81x30,Z1/1,V4
    D: 125 mm
    SB: 81 mm
    BO: 30 mm
    BOmax: 50 mm
    Z: 2
    V: 4
    nmax: 13700 min-1
    from 1 Qty £284.63
    In Stock
    *stock levels may be subject to change
    166037744 Turnblade rebating cutterhead
    HW:125x81x31,75,Z2V4
    D: 125 mm
    SB: 81 mm
    BO: 31,75 mm
    BOmax: mm
    Z: 2
    V: 4
    nmax: min-1
    from 1 Qty £284.63
    In Stock
    *stock levels may be subject to change
    • 24723 Turnblade rebating cutterhead
      MC:125x81x30,Z1/1,V4
      D: 125 mm
      SB: 81 mm
      BO: 30 mm
      BOmax: 50 mm
      Z: 2
      V: 4
      nmax: 13700 min-1
      from 1 Qty £284.63
      In Stock
      *stock levels may be subject to change
    • 166037744 Turnblade rebating cutterhead
      HW:125x81x31,75,Z2V4
      D: 125 mm
      SB: 81 mm
      BO: 31,75 mm
      BOmax: mm
      Z: 2
      V: 4
      nmax: min-1
      from 1 Qty £284.63
      In Stock
      *stock levels may be subject to change

    Spare knives:
    Id BEZ ABM
    5074 Turnblade knife
    HW-30F:40x8x1.5
    		BEZ: Turnblade knife ABM: HW-30F:40x8x1.5
    In Stock
    *stock levels may be subject to change
    5075 Turnblade knife
    HW-30F:50x8x1.5
    		BEZ: Turnblade knife ABM: HW-30F:50x8x1.5
    In Stock
    *stock levels may be subject to change
    5076 Turnblade knife
    HW-30F:60x8x1.5
    		BEZ: Turnblade knife ABM: HW-30F:60x8x1.5
    In Stock
    *stock levels may be subject to change
    601613 Turnblade knife
    HW:80x8x1,5
    		BEZ: Turnblade knife ABM: HW:80x8x1,5
    In Stock
    *stock levels may be subject to change
    5115 Turnblade spur VS2
    HW-F:19x19x2
    		BEZ: Turnblade spur VS2 ABM: HW-F:19x19x2
    from 1 Qty £2.26
    In Stock
    *stock levels may be subject to change
    • 5074 Turnblade knife
      HW-30F:40x8x1.5
      BEZ: Turnblade knife
      ABM: HW-30F:40x8x1.5
      In Stock
      *stock levels may be subject to change
    • 5075 Turnblade knife
      HW-30F:50x8x1.5
      BEZ: Turnblade knife
      ABM: HW-30F:50x8x1.5
      In Stock
      *stock levels may be subject to change
    • 5076 Turnblade knife
      HW-30F:60x8x1.5
      BEZ: Turnblade knife
      ABM: HW-30F:60x8x1.5
      In Stock
      *stock levels may be subject to change
    • 601613 Turnblade knife
      HW:80x8x1,5
      BEZ: Turnblade knife
      ABM: HW:80x8x1,5
      In Stock
      *stock levels may be subject to change
    • 5115 Turnblade spur VS2
      HW-F:19x19x2
      BEZ: Turnblade spur VS2
      ABM: HW-F:19x19x2
      from 1 Qty £2.26
      In Stock
      *stock levels may be subject to change

    Alternative turnblade knife qualities see section Knives and Spare Parts

    Spare parts:
    Id BEZ ABM
    7808 Countersink screw, Torx® 20
    M5x8.5
    		BEZ: Countersink screw, Torx® 20 ABM: M5x8.5
    In Stock
    *stock levels may be subject to change
    7442 Clamping screw w. disc, Torx® 25
    M6x18.5
    		BEZ: Clamping screw w. disc, Torx® 25 ABM: M6x18.5
    In Stock
    *stock levels may be subject to change
    • 7808 Countersink screw, Torx® 20
      M5x8.5
      BEZ: Countersink screw, Torx® 20
      ABM: M5x8.5
      In Stock
      *stock levels may be subject to change
    • 7442 Clamping screw w. disc, Torx® 25
      M6x18.5
      BEZ: Clamping screw w. disc, Torx® 25
      ABM: M6x18.5
      In Stock
      *stock levels may be subject to change

    Leitz UK have many more products available over those you can see on the online shop.

    Please contact our Customer Service Team for further details.
