Cutters with shank

Grooving router cutter in turnblade design, Z 1, without plunging tip

To Purchase Selection
Tungsten carbide
Tungsten carbide
Spiral boring
Spiral boring
Grooving, sizing
Grooving, sizing
Manual feed
Manual feed
Mechanical knife clamping, reversible
Mechanical knife clamping, reversible

Information

Information
Application: Router cutter for sizing and grooving to finish quality.
Machine:

Portable routers, limited suitable: stationary routers with/without CNC control, machining centres.

Workpiece material: Softwood, chipboard and fibre materials (MDF, HDF etc.), uncoated, plastic coated, veneered etc.
Technical information:

Tungsten carbide turnblade knife clamped by wedge. Design without plunging tip only suitable for ramp plunging. Design with plunging tip limited suitable for axial plunging.

Tool Selection
Id D
mm
GL
mm
NL
mm
S
mm
DRI
41624 Turnblade router cutter
HW/D8/NL20/S10x40/L65/Z1/RH
D: 8 mm
GL: 65 mm
NL: 20 mm
S: 10x40 mm
DRI: RL
In Stock
*stock levels may be subject to change
41631 Turnblade router cutter
HW/D9/NL20/S10x40/L65/Z1/RH
D: 9 mm
GL: 65 mm
NL: 20 mm
S: 10x40 mm
DRI: RL
In Stock
*stock levels may be subject to change
41638 Turnblade router cutter
HW/D10/NL20/S10x40/L65/Z1/RH
D: 10 mm
GL: 65 mm
NL: 20 mm
S: 10x40 mm
DRI: RL
In Stock
*stock levels may be subject to change
41643 Turnblade router cutter
HW/D10/NL25/S10x40/L70/Z1/RH
D: 10 mm
GL: 70 mm
NL: 25 mm
S: 10x40 mm
DRI: RL
In Stock
*stock levels may be subject to change
41667 Turnblade router cutter
HW/D12/NL30/S10x40/L76/Z1/RH
D: 12 mm
GL: 76 mm
NL: 30 mm
S: 10x40 mm
DRI: RL
In Stock
*stock levels may be subject to change
41679 Turnblade router cutter
HW/D14/NL40/S12x40/L86/Z1/RH
D: 14 mm
GL: 86 mm
NL: 40 mm
S: 12x40 mm
DRI: RL
In Stock
*stock levels may be subject to change
41685 Turnblade router cutter
HW/D16/NL50/S12x40/L99/Z1/RH
D: 16 mm
GL: 94 mm
NL: 50 mm
S: 12x40 mm
DRI: RL
In Stock
*stock levels may be subject to change
41714 Turnblade router cutter
HW/D16/NL50/S16x50/L109/Z1/RH
D: 16 mm
GL: 109 mm
NL: 50 mm
S: 16x50 mm
DRI: RL
In Stock
*stock levels may be subject to change
  • 41624 Turnblade router cutter
    HW/D8/NL20/S10x40/L65/Z1/RH
    D: 8 mm
    GL: 65 mm
    NL: 20 mm
    S: 10x40 mm
    DRI: RL
    In Stock
    *stock levels may be subject to change
  • 41631 Turnblade router cutter
    HW/D9/NL20/S10x40/L65/Z1/RH
    D: 9 mm
    GL: 65 mm
    NL: 20 mm
    S: 10x40 mm
    DRI: RL
    In Stock
    *stock levels may be subject to change
  • 41638 Turnblade router cutter
    HW/D10/NL20/S10x40/L65/Z1/RH
    D: 10 mm
    GL: 65 mm
    NL: 20 mm
    S: 10x40 mm
    DRI: RL
    In Stock
    *stock levels may be subject to change
  • 41643 Turnblade router cutter
    HW/D10/NL25/S10x40/L70/Z1/RH
    D: 10 mm
    GL: 70 mm
    NL: 25 mm
    S: 10x40 mm
    DRI: RL
    In Stock
    *stock levels may be subject to change
  • 41667 Turnblade router cutter
    HW/D12/NL30/S10x40/L76/Z1/RH
    D: 12 mm
    GL: 76 mm
    NL: 30 mm
    S: 10x40 mm
    DRI: RL
    In Stock
    *stock levels may be subject to change
  • 41679 Turnblade router cutter
    HW/D14/NL40/S12x40/L86/Z1/RH
    D: 14 mm
    GL: 86 mm
    NL: 40 mm
    S: 12x40 mm
    DRI: RL
    In Stock
    *stock levels may be subject to change
  • 41685 Turnblade router cutter
    HW/D16/NL50/S12x40/L99/Z1/RH
    D: 16 mm
    GL: 94 mm
    NL: 50 mm
    S: 12x40 mm
    DRI: RL
    In Stock
    *stock levels may be subject to change
  • 41714 Turnblade router cutter
    HW/D16/NL50/S16x50/L109/Z1/RH
    D: 16 mm
    GL: 109 mm
    NL: 50 mm
    S: 16x50 mm
    DRI: RL
    In Stock
    *stock levels may be subject to change

RPM:

D 8 - 12 mm: n = 18000 - 24000 min-1
D 14 - 20 mm: n = 16000 - 24000 min-1
