Tungsten carbide
Sawing along grain
Tipped tool
Information
| Application: | For cutting along grain - shoulder and trimming cuts. |
|---|---|
| Machine: | Edging, single blade, multi blade saws as well as saws with one or two spindles. |
| Workpiece material: | Softwood and hardwood wet and dry. |
| Technical information: | Large gullet area and large lateral tooth protrusion. For universal use in dry and wet soft and hard woods. Design without raker blades. Partially suitable for larger cutting depths and the use in frozen woods. |
Tool Selection
| Id |
D mm |
SB mm |
TDI mm |
BO mm |
NLA mm |
Z |
ZF |
SW ° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
165108
Circular sawblade, middle cut
HW:200x3.2/2.2x30,Z18,FZ |
D:
200
mm
|
SB:
3.2
mm
|
TDI:
2,2
mm
|
BO:
30
mm
|
NLA:
KNL
mm
|
Z:
18
|
ZF:
FZ
|
SW:
25
°
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
In Stock
*stock levels may be subject to change
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
165109
Circular sawblade, middle cut
HW:210x3.2/2.2x30,Z18,FZ |
D:
210
mm
|
SB:
3.2
mm
|
TDI:
2,2
mm
|
BO:
30
mm
|
NLA:
KNL
mm
|
Z:
18
|
ZF:
FZ
|
SW:
20
°
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
In Stock
*stock levels may be subject to change
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
165110
Circular sawblade, middle cut
HW:250x3.2/2.2x30,Z18,FZ |
D:
250
mm
|
SB:
3.2
mm
|
TDI:
2,2
mm
|
BO:
30
mm
|
NLA:
KNL
mm
|
Z:
18
|
ZF:
FZ
|
SW:
20
°
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
In Stock
*stock levels may be subject to change
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
165111
Circular sawblade, middle cut
HW:300x3.2/2.2x30,Z24,FZ |
D:
300
mm
|
SB:
3.2
mm
|
TDI:
2,2
mm
|
BO:
30
mm
|
NLA:
KNL
mm
|
Z:
24
|
ZF:
FZ
|
SW:
20
°
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
In Stock
*stock levels may be subject to change
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
165113
Circular sawblade, middle cut
HW:350x3.2/2.2x30,Z24,FZ |
D:
350
mm
|
SB:
3.2
mm
|
TDI:
2,2
mm
|
BO:
30
mm
|
NLA:
KNL
mm
|
Z:
24
|
ZF:
FZ
|
SW:
20
°
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
In Stock
*stock levels may be subject to change
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
165114
Circular sawblade, middle cut
HW:400x4/2.8x30,Z28,FZ |
D:
400
mm
|
SB:
4.0
mm
|
TDI:
2,8
mm
|
BO:
30
mm
|
NLA:
KNL
mm
|
Z:
28
|
ZF:
FZ
|
SW:
20
°
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
In Stock
*stock levels may be subject to change
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
165115
Circular sawblade, middle cut
HW:450x4/2.8x30,Z28,FZ |
D:
450
mm
|
SB:
4.0
mm
|
TDI:
2,8
mm
|
BO:
30
mm
|
NLA:
KNL
mm
|
Z:
28
|
ZF:
FZ
|
SW:
20
°
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
In Stock
*stock levels may be subject to change
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
165116
Circular sawblade, middle cut
HW:500x4/2.8x30,Z32,FZ |
D:
500
mm
|
SB:
4.0
mm
|
TDI:
2,8
mm
|
BO:
30
mm
|
NLA:
KNL
mm
|
Z:
32
|
ZF:
FZ
|
SW:
20
°
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
In Stock
*stock levels may be subject to change
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
-
165108 Circular sawblade, middle cut
HW:200x3.2/2.2x30,Z18,FZD: 200 mmSB: 3.2 mmTDI: 2,2 mmBO: 30 mmNLA: KNL mmZ: 18ZF: FZSW: 25 °In Stock*stock levels may be subject to change -
165109 Circular sawblade, middle cut
HW:210x3.2/2.2x30,Z18,FZD: 210 mmSB: 3.2 mmTDI: 2,2 mmBO: 30 mmNLA: KNL mmZ: 18ZF: FZSW: 20 °In Stock*stock levels may be subject to change -
165110 Circular sawblade, middle cut
HW:250x3.2/2.2x30,Z18,FZD: 250 mmSB: 3.2 mmTDI: 2,2 mmBO: 30 mmNLA: KNL mmZ: 18ZF: FZSW: 20 °In Stock*stock levels may be subject to change -
165111 Circular sawblade, middle cut
HW:300x3.2/2.2x30,Z24,FZD: 300 mmSB: 3.2 mmTDI: 2,2 mmBO: 30 mmNLA: KNL mmZ: 24ZF: FZSW: 20 °In Stock*stock levels may be subject to change -
165113 Circular sawblade, middle cut
HW:350x3.2/2.2x30,Z24,FZD: 350 mmSB: 3.2 mmTDI: 2,2 mmBO: 30 mmNLA: KNL mmZ: 24ZF: FZSW: 20 °In Stock*stock levels may be subject to change -
165114 Circular sawblade, middle cut
HW:400x4/2.8x30,Z28,FZD: 400 mmSB: 4.0 mmTDI: 2,8 mmBO: 30 mmNLA: KNL mmZ: 28ZF: FZSW: 20 °In Stock*stock levels may be subject to change -
165115 Circular sawblade, middle cut
HW:450x4/2.8x30,Z28,FZD: 450 mmSB: 4.0 mmTDI: 2,8 mmBO: 30 mmNLA: KNL mmZ: 28ZF: FZSW: 20 °In Stock*stock levels may be subject to change -
165116 Circular sawblade, middle cut
HW:500x4/2.8x30,Z32,FZD: 500 mmSB: 4.0 mmTDI: 2,8 mmBO: 30 mmNLA: KNL mmZ: 32ZF: FZSW: 20 °In Stock*stock levels may be subject to change
Explanation of abbreviations
D
Diameter
SB
Cutting width
TDI
Thickness of tool
BO
Bore diameter / interface
NLA
Pinhole dimensions
Z
Number of teeth
ZF
Tooth shape
SW
Cutting angle
